KDE41SS3 41kVA Diesel Generator – Reliable Power in UAE & GCC
Experience robust and reliable power with the KDE41SS3 Diesel Generator from Diesel Power, engineered for industrial, commercial, and backup applications across the UAE, Saudi Arabia, Kuwait, Qatar, Bahrain, Oman. This generator delivers 41kVA (33kW) standby power and 38kVA (30kW) prime power at 1500 RPM.
Why Choose KDE41SS3 Diesel Generator in the UAE and GCC?
Highlights
- 🔧 Powerful Diesel Engine – ZH4100ZD four-cylinder, water-cooled, turbocharged, direct injection diesel engine with 3.61L displacement and 1500 RPM rated speed for maximum durability and efficiency.
- ⚡ High-Performance Alternator – KDE 184H alternator with 12-wire reconnectable stator, H-class insulation, and SX460 AVR providing ±1.0% voltage regulation for stable power output.
- 💰 Excellent Fuel Economy – Outstanding fuel consumption of only 256 g/kWh at prime power, reducing operating costs for long-term use across GCC industrial applications.
- 🛡️ Comprehensive Protection – Features high engine temperature, low oil pressure, over/under speed, over/under voltage, over current, and fail to start protection with auxiliary inputs.
- 📊 Precision Measurement Display – Real-time monitoring of mains/generator voltage, current, frequency, active/kVA power, power factor, hour count, cumulative kWh, and start battery voltage.
- 🌍 Built for GCC Conditions – 50Hz frequency, 230/400V rated voltage, water-cooled system with radiator and blowing fan, designed to withstand demanding industrial environments across the Middle East.
Specifications
| Brand |
Diesel Power |
Model No. |
KDE41SS3 |
| Standby Power |
41 kVA / 33 kW |
Prime Power |
38 kVA / 30 kW |
| Frequency |
50 Hz |
Rated Voltage |
230/400 V |
| Rated Speed |
1500 RPM |
Engine Model |
ZH4100ZD |
| Engine Type |
4-Cylinder, 4-Stroke, Water-Cooled, In-Line |
Induction System |
Turbocharged |
| Combustion System |
Direct Injection |
Bore x Stroke |
100 x 115 mm |
| Displacement |
3.61 L |
Compression Ratio |
17.1 |
| Lubrication Capacity |
13 L |
Coolant Capacity |
13 L |
| Fuel Consumption (Prime) |
256 g/kWh |
Alternator Model |
KDE 184H |
| Alternator Control |
Self Excited with SX460 AVR |
Voltage Regulation |
±1.0% |
| Insulation System |
Class H |
Protection Rating |
IP23 |
| Stator Winding |
Double Layer Lap, 2/3 Pitch, 12 Leads |
Waveform Distortion |
<1.5% (No Load), <4.0% (Balanced Load) |
| Maximum Overspeed |
2160 Rev/Min |
Bearing (Non-Drive End) |
BALL.6306-2RS (ISO) |
| Packing Crate Size |
61.5 x 48.5 x 56 cm |
THF (Telephone Interference) |
<2% (50Hz) |
| Engine Length |
1036 mm |
Engine Width |
490 mm |
| Engine Height |
975 mm |
Dry Weight (Engine) |
380 kg |
|
